Corrosion Resistant Alloy 22 Bar

Alloy 22 is a fully austenitic, nickel-chromium-molybdenum-tungsten alloy with better overall corrosion resistance compared to other nickel-chromium-molybdenum alloys, including alloy C-276, alloy C4 and alloy 625. The high chromium content provides good resistance to oxidizing media while the molybdenum and tungsten content gives good resistance to reducing media. This combination of corrosion resistance makes alloy 22 particularly useful in applications where mixed acids are present.

You can purchase bar in standard lengths or we offer cut-to-length services with our bar processing equipment. If you require further processing, we offer machining services including: turning, grinding, polishing, milling, drilling, tapping, threading and boring.


ASTM: B574, B5641
ASME: SB574, SB5641
VdTÜV: 479
1On diameters > 3.5″, B564/SB564 is dual certified.
*EN10204-3.1 applies to all product forms.


1/8” to 11” diameter
*additional sizes available upon request.

Alloy 22 Bar Processing Services

Alloy 22 Bar Chemical Composition (%)

(Ni) Nickel Remainder
(Cr) Chromium 20.0 to 22.5
(Mo) Molybdenum 12.5 to 14.5
(W) Tungsten 2.5-3.5
(Co) Cobalt 2.5 max
(Fe) Iron 2.0-6.0
(Mn) Manganese 0.50 max
(V) Vanadium 0.35 max
(Si) Silicon 0.08 max
(P) Phosphorus 0.02 max
(S) Sulfur 0.02 max
(C) Carbon 0.015 max


Contact one of our experienced team members to help find what you’re looking for in our extensive inventory of corrosion resistant alloy products and value-added services.
